Product description

• For single or multiple drain use(see installation instructions)
• Single – 3" sump depth:
• Floor: 166 GPM at 4.8 fpsWall: 96 GPM at 2.8 fps
• Floor/wall: 53 GPM at 1.5 fps 11.2 square inch opening

• Additional sump versions also available
• #316 stainless steel screws
• Manufactured from superior UV-resistant engineered polymers
• Meets or exceeds ANSI/APSP 16-2011and NSF 50-2008 national standards and ASTM G154 UV testing
• Listed with IAPMO R&T
• 10" Round Solid Riser Ring also sold separately part # 10AVRRxxx

Features and details

• Also fits: 10" Waterway and Color Match

• 10" Round Solid Riser Ring also sold separately part # 10AVRRxxx

• The xxx in all AquaStar part numbers is the color number

• Sold with 10AVRXXX, not sold separately


Resources

Spec Sheet
SOFA Installation Instructions
VGBA 2017 Product Specifications

Warranty

Limited Warranty: AquaStar is committed to and takes pride in the quality products that it manufactures. Accordingly, AquaStar maintains high standards for the materials and workmanship that it invests in its products. AquaStar warrants its products to be free from defects in material and workmanship for a period of one year from the date of original installation. This limited warranty will be applicable only if the product manufactured by AquaStar is the sole and exclusive cause of a defect. Products that fail or become defective during the warranty period, except as a result of color-fading, improper installation, bad water chemistry, accidents or negligence on behalf of the owner, freezing, earthquakes, fire, floods or other acts of nature, shall be repaired or replaced at Aqua- Star’s option.
