AquaStar 18" Square Mud Frame with Four 9" Square MoFlow Suction Outlet Cover | for 3/4" Deep Retrofits | White | 18MFNF101

AquaStar 18" Square Mud Frame with Four 9" Square MoFlow Suction Outlet Cover | for 3/4" Deep Retrofits | White | 18MFNF101 AquaStar 18" Square Mud Frame with Four 9" Square MoFlow Suction Outlet Cover | for 3/4" Deep Retrofits | White | 18MFNF101
$148.48

Quantity:
Platinum Preferred Manufacturer
  • Grates fit: AquaStar (standard 18" square frames), Pentair (#1 selling) with 3/4" deep existing Part # 18MFNFxxx window grid frame and 4x4 screw hole pattern
  • For single or multiple drain use 6" sump depth / min. 3" pipe
  • Replace every five years from the date of installation
  • Manufactured from superior UV-resistant engineered polymers
  • The xxx in all AquaStar part numbers is the color number
OVERVIEW
18" Square Mud Frame with Four 9" Square MoFlow Suction Outlet Cover | for 3/4" Deep Retrofits White

Features
  • For single or multiple drain use 6" sump depth / min. 3" pipe
  • Single
    • Floor only: 293 GPM at .6 fps
  • When 1.0 or 1.5 fps installations are not required, always use the lower tested flow rate
  • 147.1 square inch opening
  • Trademarked VGB compliance button easily identifies VGB 2008 compliant cover from on deck and underwater
  • #316 stainless steel screws
  • Manufactured from superior UV-resistant engineered polymers
  • See installation instructions for details and special requirements
  • All components (covers, frame, screws) meet or exceed ANSI/APSP 16-2011 and
  • NSF/ANSI 50-2009a national standards and ASTM G154 UV testing exposure
  • Replace every five years from the date of installation
  • 4 per case


Brand: AQUASTAR
