Product description

• Single
• Floor/wall: 1531 GPM at 1.4 fps
• Sump Depth: 12'' Minimum
• 352 square inch opening
• Trademarked VGB compliance button easily identifies VGB 2008 compliant
• cover from on deck and underwater
• #316 stainless steel screws
• Manufactured from superior UV-resistant engineered polymers
• See installation instructions for details and special requirements
• Installs flat - level with finish
• All components (covers, frame, screws) meet or exceed ANSI/APSP 16-2011 andNSF/ANSI 50-2009a national standards and ASTM G154 UV testing exposure
• Replace every five years from the date of installation

Features and details

• Unblockable! No second suction outlet or backup SVRS required

• Also available with four grates only for 3/4" deep retrofits p/n 24NFxxx

• Manufactured from superior UV-resistant engineered polymers

• The xxx on Aquastar part numbers is the color number


Resources

Spec Sheet
VGB Series Instructions

Warranty

Limited Warranty: AquaStar is committed to and takes pride in the quality products that it manufactures. Accordingly, AquaStar maintains high standards for the materials and workmanship that it invests in its products. AquaStar warrants its products to be free from defects in material and workmanship for a period of one year from the date of original installation. This limited warranty will be applicable only if the product manufactured by AquaStar is the sole and exclusive cause of a defect. Products that fail or become defective during the warranty period, except as a result of color-fading, improper installation, bad water chemistry, accidents or negligence on behalf of the owner, freezing, earthquakes, fire, floods or other acts of nature, shall be repaired or replaced at Aqua- Star’s option.
