Product description

• For single or multiple drain use in gunite, steel, vinyl, fiberglass and tile pools and spas (see installation instructions)
• Single – sumpless
• Floor/wall (2" pipe): 224 GPM at 6.3 fps
• Floor (1½" pipe): 177 GPM at 5.9 fps
• Wall (1½" pipe): 122 GPM at 3.4 fps
• 11.4 square inch opening
• Hydro-Air retrofit version also available p/n 6HPHAxxx
• Trademarked VGB compliance button easily identifies VGB 2008 compliant cover from on deck and underwater
• #316 stainless steel screws
• Manufactured from superior UV-resistant engineered polymers
• All components meet or exceed ANSI/APSP 16-2011 and NSF 50-2008 national standards and ASTM G154 UV testing exposure
• Listed with IAMPO R&T
• Eight different adapter plates are sold separately, available for sumpless connections to 1022s, 1.5" female adapters, 1.5" and 2" inside and outside slip and threads as well as existing HydroAir wall fittings #10-6015S and 10-6304S (both with brass inserts)

Features and details

• Manufactured from superior UV-resistant engineered polymers

• The xxx in all AquaStar part numbers is the color number

• Picture: White

• Product: TAN


Resources

Spec Sheet
SOFA Installation Instructions

Warranty

Limited Warranty: AquaStar is committed to and takes pride in the quality products that it manufactures. Accordingly, AquaStar maintains high standards for the materials and workmanship that it invests in its products. AquaStar warrants its products to be free from defects in material and workmanship for a period of one year from the date of original installation. This limited warranty will be applicable only if the product manufactured by AquaStar is the sole and exclusive cause of a defect. Products that fail or become defective during the warranty period, except as a result of color-fading, improper installation, bad water chemistry, accidents or negligence on behalf of the owner, freezing, earthquakes, fire, floods or other acts of nature, shall be repaired or replaced at Aqua- Star’s option.
