Blue White F-300 Series 2" PVC Flowmeter | 40-150 GPM | F-30200P

Name: Blue White F-300 Series 2" PVC Flowmeter | 40-150 GPM | F-30200P
Brand: Blue White Industries
SKU: 11923
Availability: InStock

$121.00

Pitot Tube (impact tube) design makes it easy to install on existing pipe. Acceptable for outdoor installations (direct sunlight okay).

Features

Reduced straight run pipe requirements by 50%
Measures flow from 2 to 10 feet per second (pool industry standard)
Resistant PVDF internal float materials
One piece machined acrylic body
No metals in fluid path. Safe to use with salt chlorine generators
Mounts to existing pipe. No unions or adapters required
Models for mounting on horizontal or vertical pipe
Mounting clamps and gasket included

Specifications

Pipe Requirements: IPS inch pipe size (ASTM-D-1785)
Max. Psi (bar): 150 PSI (10.3 bar) @ 70 F (21 C)
Max. fluid temp.: 190 F (88 C) @ 0 PSI
Max. ambient temp.: 14 to 110 F/ -10 to 43 C
Note: Temperature & Pressure ratings of meter only. Actual pipe rating may vary
Full scale accuracy: +/- 5%
Power requirement: No power required
Enclosure: NEMA 4X (IP56)
Approximate shipping wt:
1"-4" units: 1 lb. (.45 kg)
6"-8"units: 2 lb. (.91 kg)

Materials of Construction

Meter Body:Cast Acrylic
Float: PVDF
Gasket: Neoprene
Pipe Clamp: 300 series Stainless Steel

Installation Requirements

Minimum Straight Pipe Length Requirements - The meter's accuracy is affected by disturbances such as pumps, elbows, tees, valves, etc., in the flow stream. Install the meter in a straight run of pipe as far as possible from any disturbances. The distance required for accuracy is 10 times the nominal pipe diameter before the meter and 4 times the nominal pipe diameter after the meter.

Mounting location

F series meters must be mounted at the vertical (twelve o'clock) position
Must be mounted on horizontal pipe only
U & D series meters must be mounted on vertical pipe only
The pipe must be completely full of water at all times
See the minimum straight length of pipe requirement chart above
The meter can accurately measure flow from one direction only
U-series meters measure upward flows only
D-series meters measure downward flows only
