Compact Size for Tight Installation
Features
- Polysulfone meter body resists high temperatures and pressures
- Compact size for tight installation spaces
- 316SS or Hastelloy rod guided float
- Union connections for easy installation and maintenance
- Adjustable flow rate setpoint indicator
- Direct reading permanent scale
Specifications
-
Pipe Male NPT: 3/4"
- Max. working pressure: 175 PSI (10.3 bar) @ 70 F (21 C)
- Max. fluid temperature: 212 F (100 C) @ 0 PSI
- Full scale accuracy: +/- 4%
- Calibration fluid: Water, specific gravity 1.0
- Scale length: 2” (50mm) approx.
- Environment: Not for direct sunlight exposure
- Approximate shipping wt: 0.5 lb. (.23 kg)
Material of Construction
- Meter Body: Polysulfone
- Adapters: Polysulfone M/NPT (Optional F/NPT available)
- Guide Rod Holder: Polysulfone
- O-ring seals: Viton (optional EP)
- Union Nuts (non wetted): Polysulfone
- Float: 316SS, PVDF, Hastelloy or Teflon (per model)
- Guide Rod: 316SS
