Product description

• Bubbler Plate
• Flush-Mount Return Fitting that Fits Inside 2" Pipe
• Juction Box with Square Lid
• Junction Box With Round Lid

• Round Lid, Adjustable collar
• New weir clip lock secures the clips in the weir door
• Weir plate with easy snap in and out locks
• Self-contained gunite grip, water stop on face plate to prevent water leaks
• Large self-contained basket with lock-in feature (will not float)
• Pre-installed O-ring for float assembly
• Underwater dampers on face plate for noise reduction on weir plate – especially on windy days
• Super strong engineered polymer upper housing
• Extra heavy duty PVC lower unit (no transitional glue required)
• 2½" outside slip and 2" inside slip (outside skimmer)
• 2" threads for pressure testing (inside skimmer)
• Built-in overflow or fill line knock out
• Upper housing has pre-cut rebar cut outs with pre-drilled holes for tie wire
• Additional box inside skimmer box for basket, float assembly and weir plate (so assembly does not get lost on job site)
• Skimmer Lid and Collar G154 UV tested
• NSF 50 approved for commercial use, 25 GPM min, 55 GPM max – approved for residential use up to 100 GPM
• Optional custom name/logo engraved on lid (requires minimum 100 piece lid order)

Features and details

• Self-contained gunite grip, water stop on face plate to prevent water leaks

• Large self-contained basket with lock-in feature (will not float)

• Weir plate with easy snap in and out locks

• The xxx in all AquaStar part numbers is the color number

• To be used with the Ultimate Ozone

• Picture: White
  Product: Light Gray


Specifications

Pool Type

In-Ground

Application

Gunite

Size

2"

Resources

Data Sheet
Installation Instructions

Warranty

Limited Warranty: AquaStar is committed to and takes pride in the quality products that it manufactures. Accordingly, AquaStar maintains high standards for the materials and workmanship that it invests in its products. AquaStar warrants its products to be free from defects in material and workmanship for a period of one year from the date of original installation. This limited warranty will be applicable only if the product manufactured by AquaStar is the sole and exclusive cause of a defect. Products that fail or become defective during the warranty period, except as a result of color-fading, improper installation, bad water chemistry, accidents or negligence on behalf of the owner, freezing, earthquakes, fire, floods or other acts of nature, shall be repaired or replaced at Aqua- Star’s option.
