Product description

• Rugged All-Brass Headers
  Resist corrosion, and are easily removed for inspection or service. AB 1953 low-lead complaint


• Cupro-nickel Finned-tube
  Single bank, straight through design delivers lowest pressure drop. Integral fins have ten times the heat transfer surface of plain tubes. Cupro-nickel tubes provide superior chemical resistance over copper for tough commercial installations


• On-off Operation


• Corrosion Resistant Steel
  Fittings are brushgalvanized against rust. Heat shields are corrosion-resistant steel. Jacket has Polytuf powder coat finish


• 24-Volt Controls
  Are totally enclosed for protection. Cover is easily removed for inspection and service


• Floating Return Header
  Immunizes heat exchanger to thermal shock


• Tube Sheet and “O” Ring Construction
  Eliminates the repair and maintenance problems associated with rolling tubes directly into a casting


• Interlocking Refractory Panels

• With sealed corners reduce radiation losses


• Stainless Steel Burners

• Maintain precise combustion, burn quietly and won’t clog or corrode


• Slide-out Burner Tray
  Allows easy inspection and service


• Spark-to-Pilot Ignition
  The most dependable ignition method available.

• Unitherm Governor (std on 926-1223)
  This provides a temperature-activated valve inside the header which varies flow through the heat exchanger. No pump on the heater. Flow comes from an external source
• H-Style Bypass (std on 1336-1758)
  This provides a larger manually-set bypass to bring heated water back to the inlet, raising the temp inside the heat exchanger. For size 1287, the H-bypass is horizontal with a rear-mounted pump. For sizes 1414-1758, the H-bypass is vertical with a front-mounted pump
• None (field-supplied)
  Protection provided by others and mounted in the field
• Cold-Water Run (CWR)
  This approach uses digital controls to vary the performance of a variable-speed pump which governs how much heated water is returned to the inlet. Performance is adjusted in real time

Features and details

• Clubs. Universities. Municipalities. Water sport Centers. Large residential pools

• Up to 82% thermal efficiency

• Fuel-saving electronic ignition

• Precision water temperature control to ± 1∞F

• Low operating cost. Low maintenance cost. Easy service


Resources

Brochure
Installation and Operation
Spec Sheet
Specifications

Warranty

Raypak, Inc. (“Raypak”) warrants to the original owner that the below model pool and spa heater (the “Heater”) when installed in the contiguous 48 states of the United States of America with a pool or spa by a properly licensed installer will be free from defects in materials and workmanship under normal use and service for the Applicable Warranty Period. The foregoing warranty will extend to subsequent owners solely as required by applicable state law. Under this Limited Warranty, Raypak will, at its option, repair or furnish a replacement for any defective part of the HEATER. The repair or replacement will be warranted for only the unexpired portion of the original Applicable Warranty Period (as defined below). * THIS WARRANTY PERIOD IS NOT AVAILABLE FOR HEATERS INSTALLED ANYWHERE OTHER THAN A SINGLE-FAMILY RESIDENTIAL DWELLING, AS THIS HEATER IS NOT INTENDED FOR COMMERCIAL INSTALLATION.

Warranty Information
