Raypak Compact Series Digital Pool Heat Pump 70-75BTU R-410A | M4350ti-E R4350ti-E 013602

This item has been discontinued.
Raypak Compact Series Digital Pool Heat Pump 70-75BTU R-410A | M4350ti-E R4350ti-E 013602
Raypak Compact Series Digital Pool Heat Pump 70-75BTU R-410A | M4350ti-E R4350ti-E 013602
Raypak Compact Series Digital Pool Heat Pump 70-75BTU R-410A | M4350ti-E R4350ti-E 013602
Features:
Cabinet
  • Exclusive DuraSteel™ Powder-Coated, non-corrosive cabinet is more durable than plastic heat pump cabinets. Same rugged steel construction used by all the major air conditioner manufacturers.
Evaporator Coils
  • Large Air Coils - Raised lanced-fin design maximizes heating at lower temperatures. Raypak engineered coils are highly optimized to meet our specific design requirements. From the proper fins per inch to advanced distribution circuiting. We are the only heat pump pool heater company to actually manufacture our own coils.
  • Venturi Fan Cowling - High-capacity 3000-cfm fan provides unrestricted air flow for better heating. Precision engineered and manufactured cabinet design eliminates unwanted air gaps. This means more air over the coil which translates to greater efficiency.
Compressor
  • Scroll Compressors are quiet and efficient compared to piston-type compressors. They provide higher efficiency, lower sound levels, superior durability and unsurpassed reliability. The unique design of a scroll compressor actually wears in over time, not out!

Heat Exchanger

  • Spiral Titanium Tube heat exchanger provides a corrosion-free waterway that can withstand the abuses of harsh pool chemistry. The spiral tube helps reduce deposit build-up and increases efficiency by performing a “scoop-and-lift” action.
  • Internal Bypass Valving automatically compensates for normal day-to-day changes in your pool’s hydraulics, maximizing heat transfer efficiency.
  • Plumbing Connections - offset 1 1/2” PVC union connections are included for ease of installation.
Controls
  • Dual Thermostats allows separate pool and spa temperature settings.
  • Exclusive Direct-Set Thermostat, our direct-set thermostat is easy to use; the temperature settings are right on the dial.  This eliminates the guesswork involved compared with some dials that use a gradient or blue-to-red “swoosh”.

Remote/Local Switch

  • Compatible with the latest automated pool control systems. Exclusive remote/local switch ends the conflict between outside control systems and the heat pump control system. Great for troubleshooting.

Diagnostic Lights

  • Six LED diagnostic lights keep you informed about the heat pump pool heater operation Power on, water flow, heat demand, compressor delay, defrost active, low refrigerant pressure.

Controls - DigitalPool/Spa Control

  • Your digital heat pump pool heater can be set to have a different target temperatures for your pool and your spa. This allows you to dial in just the right spa temperature and never have to adjust it again. The pool can be set to a lower, more energy saving temperature.

Remote Compatible

  • The digital heat pump pool heater can be easily controlled by most two-wire and three-wire remote systems.

On Board Diagnostics

  • Tells the homeowner if there is a problem. Provides the service technician with detailed diagnostic information.


Brand: Raypak
