SR Smith 6004 Series Metal Halide Illuminator, 4 Position Color Wheel | Auto-Synch | 6004-AS

SR Smith 6004 Series Metal Halide Illuminator, 4 Position Color Wheel | Auto-Synch | 6004-AS

Platinum Preferred Manufacturer
  • 450 Strand Port Capacity
  • 120 VAC 60Hz, 200W
  • Lamp life: 6000 hrs average
Q & A
  • SR Smith Lamp Assembly For 6000 Illuminator Models | Y20-6000
    SR Smith Lamp Assembly For 6000 Illuminator Models | Y20-6000

  • SR Smith Wireless Remote Control for 6004 Illuminator | RM-6000
    SR Smith Wireless Remote Control for 6004 Illuminator | RM-6000

Fiber Optic Lighting - Metal Halide Illuminator - AUTO-SYNCH
A multi-color 4-position color wheel (White, Blue, Green and Magenta), metal halide fiber optic illuminator for underwater lighting and fiber optic water features. If multiple units are required, use 6004 AS.
Product Specifications
  • Enclosure: High-Impact Outdoor Grade Polycarbonate
  • Ventilation: 110 ft3 /min.
  • Acoustic Rating: 50dB (A)
  • Weight: 20 lbs.
  • Maximim Fiber Capacity: 450 strand capacity
  • Add our optional Constant Color System to increase to
  • 600 strands
  • Voltage Requirement: 120 VAC, 60 Hz
  • Power Consumption: 200 Watts max
  • Start Current Load: 4.4 amps
  • Run Current Load: 1.8 amps
  • Type: Metal-Halide H.I.D., Proprietary Design
  • Life: 6000 Hours Average
  • Cool Down/Restrike Period: 2-3 minutes
  • Replacement Lamp Assembly No.: Y20-6000
  • Color Temperature: 4300 K
*All 6004-AS units do not require communication cables and can be synchronized with all JazzTM Light AS Units*

Brand: S.R.Smith
Q & A
Start typing your question and we'll check if it was already asked and answered. Learn More
No questions have been asked about this item. Be the first!
There are no reviews for this item. Write Review
S.R.Smith, LLC warrants to the original retail purchaser that products manufactured by S.R.Smith, when properly assembled and installed in accordance with S.R.Smith's assembly and installation instructions, and properly used and maintained, shall be free from defects in materials and workmanship for the warranty period of three (3) years from the date of retail purchase except for the following items set forth below:
  • Game Accessories (ball, pump, net): Ninety Days
  • WetDek: One Year
  • Resin Transfer Molded (RTM) Slides, Seats, Loungers, and Tables: One Year
  • Aquatic Lift System Frames (excluding the powder coated finish, which may become scratched with normal use): Five Years
  • Aquatic Lift System Electronic and Motor Components (excluding batteries): Two Years
  • Aquatic Lift batteries: One year prorated as follows: 100% of cost during the first ninety days of ownership and 50 percent of cost after ninety days and prior to expiration of one-year period. Normal maintenance and care of the unit, including charge of the battery when not in use is recommended.
  • Lighting:
Product Parts
LED Lighting - Mod-Lite, Micro, Kelo, Treo, Fiberglass, Color Light Stream
3-Years 1-Year
PoolLUX Controls- Power, Plus, Plus2, Premier
2-Years 1-Year
PT- Series
2-Years 1-Year
Wiretran Control
1-Year 1-Year
TX-30 Control
1-Year 1-Year
WPC Controls
1-Year 1-Year
Fiber Optic Illuminators - 6004 Series
3-Years 1-Year
Fiber Optic Cable
1-Year n/a
Water Features
1-Year n/a
To register your S.R.Smith product, visit the Product Registration page at: www.srsmith.com.
This information was updated on 10/07/19. For the most current information and full warranty policy please visit www.srsmith.com.
