Home Pool Drains & Drain Covers Channel Drains AquaStar 32" Channel Drain with Flat Grate Suction Outlet Cover and 3 Port Sump for Vinyl and Fiberglass | White | 32CDFLV101
NOTICE: The pool & spa industry continues to face industry-wide shortages on many products that most vendors expect to last late into 2022. ... We're allowing items to be purchased so that customers who choose to wait will have their order shipped when product is available. Most vendors are not providing any ETA on when items will be available. WE WILL EMAIL YOU RIGHT AWAY IF YOUR ITEM IS BACKORDERED.

AquaStar 32" Channel Drain with Flat Grate Suction Outlet Cover and 3 Port Sump for Vinyl and Fiberglass | White | 32CDFLV101

$257.28
AquaStar 32" Channel Drain with Flat Grate Suction Outlet Cover and 3 Port Sump for Vinyl and Fiberglass | White | 32CDFLV101
AquaStar 32" Channel Drain with Flat Grate Suction Outlet Cover and 3 Port Sump for Vinyl and Fiberglass | White | 32CDFLV101
AquaStar 32" Channel Drain with Flat Grate Suction Outlet Cover and 3 Port Sump for Vinyl and Fiberglass | White | 32CDFLV101
Trust the AquaStar line of suction outlet covers, compliant with the new Virginia Graeme-Baker Pool and Spa Safety Act.

Features
  • A single, unblockable suction outlet that exceeds the new VGB mandate and ASME/ANSI A112.19.8a-2008 standard
  • For single or multiple drain use (see installation instructions for plumbing, hydrostatic valve/drain pipe and single or multi-pump connections)
  • Single
    • Floor: 316 GPM at 3.9 fps
    • Wall: 208 GPM at 2.6 fps
    • Floor/wall: 122 GPM at 1.5 fps
  • 25.9 square inch opening
  • #316 stainless steel screws
  • Manufactured from superior UV-resistant engineered polymers
  • Three ports: bottom 2 OD, 2 ID S/S; inside 2 threaded FPT; two 2 threaded plugs included
  • Permanently attached gasket reduces gasket alignment problems
  • All components Meets or exceeds NSF 50/ASME/ANSI A112.19.8a-2008 national standards and ASTM G154 UV testing
  • Must use transitional glue when attaching to PVC pipe
  • Replace every five years from the date of installation


Brand: AQUASTAR
