Product description

• Adjustable collar
• New weir clip lock secures the clips in the weir door
• Self-contained gunite grip, water stop on face plate to prevent water leaks
• Large self-contained basket with lock-in feature (will not float)
• Underwater dampers on face plate for noise reduction on weir plate – especially on windy days
• Super strong engineered polymer upper housing
• Extra heavy duty PVC lower unit (no transitional glue required)
• 2 1/2" outside slip and 2" inside slip (outside skimmer) 2" threads for pressure testing (inside skimmer)
• Built-in overflow or fill line knock out
• Upper housing has pre-cut rebar cut outs with pre-drilled holes for tie wire
• Skimmer lid and collar G154 UV tested
• NSF 50 approved for commercial use, 25 GPM min, 55 GPM max – approved for residential use up to 100 GPM
• Optional custom name/logo engraved on lid (requires minimum 500 piece lid order)
• Unique fillable lid that will make your skimmer or autofill cover virtually disappear with any deck finish
• Bonding plate and copper wire connection meet NEC section 680.2 C.
• Conforms to UL 1081, UL 1563, CAN/CSA-C22.2
• Bonding plate is safely placed behind the skimmer basket, for constant water contact, even when the pump is off

Features and details

• New Weir Clip Lock Secures the Clips in the Weir Door

• Super Strong Engineered Polymer Upper Housing

• Self-Contained Gunite Grip, Water Stop on Face Plate to Prevent Water Leaks

• Extra Heavy Duty PVC Lower Unit (No Transitional Glue Required)

• Bonding Plate Is Safely Placed Behind the Skimmer Basket, for Constant Water Contact, Even when the Pump Is Off

• Unique Fillable Lid that will Make Your Skimmer or Autofill Cover Virtually Disappear with any Deck Finish


Specifications

Pool Type

In-Ground

Application

Gunite

Size

2-2 1/2"

Resources

Brochure
Installation Instructions

Warranty

Limited Warranty: AquaStar is committed to and takes pride in the quality products that it manufactures. Accordingly, AquaStar maintains high standards for the materials and workmanship that it invests in its products. AquaStar warrants its products to be free from defects in material and workmanship for a period of one year from the date of original installation. This limited warranty will be applicable only if the product manufactured by AquaStar is the sole and exclusive cause of a defect. Products that fail or become defective during the warranty period, except as a result of color-fading, improper installation, bad water chemistry, accidents or negligence on behalf of the owner, freezing, earthquakes, fire, floods or other acts of nature, shall be repaired or replaced at Aqua- Star’s option.
