Sundance Error Codes ILOC = Interlock failure OH = Sensor indicates water temp above acceptable limits FLO = Pressure Switch malfunction Hold = Panel buttons pressed too many times to quickly HOT-– Air blower on ICE = Freeze condition PnL = Communication error between circuit board & panel Sn1 = Hi-limit sensor malfunction Sn3 = Temp sensor malfunction “-----” = Watch dog – Water temp above acceptable limits (above 118°). Potential damage to spa equipment. Possible sensor, transformer, topside or circuit board failure
Spa Builders LX 10/15 Error codes Sn1 / 01 Nonfunctional /open high temperature sensor. Heater deactivated Sn2 / 02 Nonfunctional /open temperature sensor. Heater deactivated FL1 / 03 Pressure switch not closed when pump is running and heater is trying to heat, Heater is also deactivated FL2 / 04 Pressure switch is closed when pump is off COL / 05 Cool Condition Water Temp has dropped 20° below set temperature low speed pump & heater will activate to bring temperature to within 15° of preset; only works in economy mode ICE = Freeze condition. Water temp has reached 55°; pump & heater are activated OH = Water temp above acceptable limits (above 110°) “---” = Watchdog Water temp above acceptable limits (above 118°). Potential damage to spa equipment. Possible sensor, transformer, topside or circuit board failure
Gecko Error Codes (new style) / Hydro-Quip Error Codes 32° = Temp sensor not detected 112° Flashing = Water too hot; let cool down & system will reset itself @ 109° 3 Flashing dots on display = water fl ow problem check for closed valves, dirty fi lters, water level, pump/ wet end operation / defective pressure switch. Flashing dots & light lit on circuit board = Hi-limit trip. Reset power to clear Temp reads correct water temp = Good; if incorrect replace sensor Inverted Display = Press Filter key for 5 seconds (certain models only) Pump starts by itself for 1 minute on several occasions & Filter indicator fl ashing = Smart Winter Mode not an error but a feature (Freeze protection) Filter cycle has stopped & “Filter” indicator is fl ashing not an error but a feature; either the fi lter cycle is in a 40 minute time-out to avoid ozonator activation while spa is being used or the system has cancelled a fi lter cycle after 3 hours because water temp exceeds set point by more than 2° “Heater” indicator fl ashes when pump is on high speed. Not an error but a feature. The system is turning off the heater when pump is on high speed to limit amperage draw (jumper 1 set to “LC” mode) Temperature displays water temp “C°” or “F°”. Simply hold light button for 5 seconds to toggle. Technical note: After making any changes to any P.C.B or control system; RESET the Breaker
Lennovator Error Codes “SP” = SPA MODE ; not an error “PO” = POOL MODE; not an error “NC” = No Communication With Master Control Unit “- - “ = Data Being Sent To Master Control Unit “OP” = Temperature Sensor Failure-open “SH” = Temperature Sensor Failure-shorted “OH” = Warning, Water Temperature Over 120°f “IP” = Insuffi cient Power “FP” = Freeze Point Temperature: Set Point & Actual Water Temp Temperature Flashing On & Off - Warning - Water temperature high (109°-120°F)
