Home Pool Drains & Drain Covers

Drains & Drain Covers

We have many options and can help you determine what's right for your pool. All new pools must have a compliant (VGB) drain cover and all commercial pools must be retrofitted. More information is provided below and you can rely on PSU to help update your pool or spa.

Subcategories

4" Drain Covers & Plates

4" Drain Covers & Plates
The AquaStar line of suction outlet covers compliant with the new VGB Safety Act.
6" Drain Covers & Plates

6" Drain Covers & Plates
The AquaStar line of suction outlet covers compliant with the new VGB Safety Act.
8" Main Drains & Sumps

8" Main Drains & Sumps
Main Drains & Sumps which are VGB Safety Act Compliant.
9" Main Drains & Sumps

9" Main Drains & Sumps
The AquaStar line of suction outlet covers compliant with the new VGB Safety Act.
10" Main Drains & Sumps

10" Main Drains & Sumps
Main Drains & Sumps which are VGB Safety Act Compliant.


12" Main Drains & Sumps

12" Main Drains & Sumps
The AquaStar line of suction outlet covers compliant with the new VGB Safety Act.
18" Main Drains & Sumps

18" Main Drains & Sumps
Main Drains & Sumps which are VGB Safety Act Compliant.
20" Main Drains & Sumps

20" Main Drains & Sumps
Unblockable!
24" Main Drains & Sumps

24" Main Drains & Sumps
The AquaStar line of suction outlet covers compliant with the new VGB Safety Act.
Propeller Drains

Propeller Drains
Propeller drains easily retrofit a single drain to be VGB compliant.
Channel Drains

Channel Drains
Introducing the first single, unblockable suction outlet cover rated at 316 GPM.
Return Fittings

Return Fittings
Return Fittings are required for every pool and available in a variety of colors
Twirlybyrd Necessities

Twirlybyrd Necessities
Housing, Tool & Finishing Kits
Twirlybyrd Pool Essentials

Twirlybyrd Pool Essentials
Interchangeable Directional Pool returns
Twirlybyrd Spa Sensations

Twirlybyrd Spa Sensations
Interchangeable spa Faceplates

Resources

PRODUCTS

Click here for important U.S. Consumer Product Safety Commission regarding recalled Drain Covers.

Title XIV Virginia Graeme Baker Pool and Spa Safety Act

This act of congress was named after the granddaughter of Secretary of State James A. Baker III, who lost her life in a family spa suction entrapment during a birthday party. Her tragic passing will be forever remembered with this law.The Virgina Graeme Baker Act (VGB) was written to enhance the safety of public and private pools and spas, to reduce child drowings, to reduce the number of suction entrapment incidents and to educate people on the importance of constant supervision of children in and around water. There are federal, state and city requirements relating to compliant drain covers SVRS devices related to this law.

Federal law requires that all pool/spa drains that were manufactured distributed or sold on or after December 19, 2008 must meet ASME/ANSI A112.19.8-2007 requirements. In addition, all public pools and spas must be retrofitted with covers that meet the previous mentioned standards. Finally, all public pools and spas that have a single drain other than an unblockable drain must employ one or more SVRS device.

SVRS devices come in three main varieties:
1) Mechanical devices which let air into the circulation pump to ease the vacuum when entrapment or blockage is sensed by device.
2) Electro-mechanical devices which shut off circulation pump when entrapment or blockage is sensed.
3) Pumps or motors with built in software which shuts off circulation pump when entrapment or blockage is sensed.
