Home Pool Alternative Sanitizers DEL Advanced Sanitization Solutions DEL AOP 50 Ozone + UV Sanitation for Residential Pools | 50,000 Gallons | 220V/240V | SEC-110-26
NOTICE: The pool & spa industry continues to face industry-wide shortages on many products that most vendors expect to last late into mid-2022. We're allowing items to be purchased so that customers who choose to wait will have their order shipped when product is available. WE WILL EMAIL YOU RIGHT AWAY IF YOUR ITEM IS BACKORDERED.

DEL AOP 50 Ozone + UV Sanitation for Residential Pools | 50,000 Gallons | 220V/240V | SEC-110-26

DEL AOP 50 Ozone + UV Sanitation for Residential Pools | 50,000 Gallons | 220V/240V | SEC-110-26 DEL AOP 50 Ozone + UV Sanitation for Residential Pools | 50,000 Gallons | 220V/240V | SEC-110-26 DEL AOP 50 Ozone + UV Sanitation for Residential Pools | 50,000 Gallons | 220V/240V | SEC-110-26 DEL AOP 50 Ozone + UV Sanitation for Residential Pools | 50,000 Gallons | 220V/240V | SEC-110-26 DEL AOP 50 Ozone + UV Sanitation for Residential Pools | 50,000 Gallons | 220V/240V | SEC-110-26 DEL AOP 50 Ozone + UV Sanitation for Residential Pools | 50,000 Gallons | 220V/240V | SEC-110-26
$1,924.06

Quantity:
Silver Preferred Manufacturer
  • Advanced Plasma Gap (APG) Ozone + UV-C Oxidation
  • Destroys 99.9% of dangerous contaminants
  • The most powerful advanced sanitizer
  • Complete NSF certified AOP oxidation
  • AOP power for pools up to 50,00 gallons
RELATED ITEMS
  • DEL MDV XL Mixing De-Gas Vessel for DEL AOP Systems | MDV-100
    DEL MDV XL Mixing De-Gas Vessel for DEL AOP Systems | MDV-100

    $734.13
  • DEL MDV Mixing De-Gas Vessel for DEL OZONE Systems | MDV-10-04
    DEL MDV Mixing De-Gas Vessel for DEL OZONE Systems | MDV-10-04

    $429.45
  • DEL Replacement Ozone Module | 9-1056-01
    DEL Replacement Ozone Module | 9-1056-01

    $64.69
  • DEL Ozone Gas Line Assembly | 9-1087-01
    DEL Ozone Gas Line Assembly | 9-1087-01

    $25.07
  • DEL UV Lamp Replacement for AOP 50 | 9-1266-01
    DEL UV Lamp Replacement for AOP 50 | 9-1266-01

    $137.36
OVERVIEW
AOP: The Most Powerful Advanced Sanitizer

Through the combination of Corona Discharge Technology, Germicidal UV Light, and DEL's Advanced Plasma Gap technology, the DEL AOP lineup provides Advanced Oxidation Process in truly robust units.

The Advantages of AOP
With the use of AOP microorganisms are destroyed, chloramines are broken down and chlorine dependence is clear results
  • Destroys 99.9% of harmful contaminants
  • Quickly oxidizes Cryptosporidium parvum, Giardia, and other chlorine resistant microorganisms
  • Dramatically reduces chemical demand & increases effectiveness of residual sanitizers
  • Eliminates chemical odors, irritations, and will not damage pool systems
The Science of AOP
When germicidal UV light (UV-C) and ozone react the result is the production of hydroxyl radicals. This reaction is known as Advanced Oxidation Process, or AOP.
Hydroxyl radicals (•OH) are the most powerful oxidation agents available, quickly destroying bacteria, viruses, pathogens and other contaminants that occur in water.
Hydroxyl radicals also destroy chlorine resistant microorganisms, such as Cryptosporidium Parvum, Giardia and E.Coli.

The Power of AOP
AOP is dramatically more powerful than Chlorine and other sanitizers, and even more powerful than Ozone alone. In AOP systems, the highly unstable hydroxyl radicals react with dissolved waterborne contaminants in a series of strong oxidation reactions. This process happens almost instantaneously.

SPECIFICATIONS DEL AOP 50
Application 50,000 Gallons or less
Plumbing Connections Inlet and Outlet 2" PVC Unions
Maximum Flow Rate 50 GPM
Mounting Floor or Wall Mount
Enclosure Rating CSA/NEMA 3 | Indoor/Outdoor Installation
Voltage 240 VAC, 60 HZ, 1Ø, 0.6 Amps
Dimensions 17"H x 9.5"W x 13.5"D
Weight 45 lbs
Germicidal UV Lamp Low Pressure/High Output UV-C Germicidal
Ozone Cell APG Cells; 5 Year Life Expectancy
MDV Unit MDV XL


Brand: DEL
SPECIFICATIONS
Color
Black
Voltage
Dual
Capacity (Gallons)
50,000
Q & A
Start typing your question and we'll check if it was already asked and answered. Learn More
Browse 8 questions Browse 8 questions and 11 answers
does it eliminate the use of chlorine?
nicole b on May 19, 2018
BEST ANSWER: NO- residual chlorine of 1-2 ppm is required
CAN THE OZONE CELL BE REPLACED AFTER 3 YEARS? OR DO I HAVE TO REPLACE UNIT
Sean M on Jun 21, 2017
BEST ANSWER: Yes the ozone cells can be replaced as needed - a entire system replacement is not needed.
What size fuse does this unit use?
Billy T on May 15, 2016
BEST ANSWER: According to the documentation for the Solar Eclipse it is drawing .4 Amps at 220-240V, we do not have this on a separate circuit as it is on the same circuit as our pool pump relay 240V @ 20A. Otherwise I would recommend 220-240V @ 20A
Can this product be used in conjunction with an auto chlorine feeder?
Esen E on Jan 18, 2019
BEST ANSWER: Yes
Does this work with salt chlorine generator?
A shopper on Jul 26, 2021
BEST ANSWER: Yes, I contacted CMP the manufacturer. This does work with any salt generator, the difference is that the level of salt needed is <1 ppb vs standard level of 3-4 bbm of chlorine salt. We use our AOP 50 with a Pentair salt generator.
what ozone/uv product would recommend for a 77,000 galleon pool?
John M on Oct 23, 2015
BEST ANSWER: If you want ozone and UV you would need to go to the commercial grade equipment cmpcommercial - if you want just Ozone you can go with the EC-40 as this unit works with pools up to 100,000 gallons
what kind of test strips do we need for this system and where is the best place to get them?
A shopper on May 28, 2017
we have a 40,000 gallon pool. the pool construction is vinyl liner. will this have any negative impact on the liner?
michael h on Mar 14, 2017
REVIEWS
4.3 / 5.0
3 Reviews
5 Stars
4 Stars
3 Stars
2 Stars
1 Star
1
2
0
0
0
Rated 5 out of 5
Works Great
We have a LOT of kids in our pool during the summer months and this product has been able to keep up with them! Very clear, clean water and I'm happy! Not to mention how easy it was to install.
August 10, 2013
Rated 4 out of 5
Perfect alternative
I was looking for an alternative to chemicals to keep the pool clean. My pool guy recommended UV and Ozone. When I found this gem I was very hopeful. It's working like a charm for my pool, very satisfied with the product performance.
December 7, 2016
Rated 4 out of 5
Crystal Clear
My pool stayed crystal clear all summer and was so easy to maintain. I have told all of my friends and neighbors that have pools about this system.
July 9, 2014
RESOURCES
WARRANTY
Custom Molded Products, LLC takes great pride in the quality products that it manufactures. The company maintains high standards for the materials and workmanship that it invests in its products. Accordingly, Custom Molded Products makes this express Limited Warranty with respect to products manufactured solely by Custom Molded Products, LLC, as follows:

Custom Molded Products warrants its products to be free of defects in material and workmanship for a period of one (1) year from the date of original purchase of the Custom Molded Products product unless otherwise noted.

Exceptions to standard CMP one (1) year warranty:
  • DEL UV-C 50: 2 year warranty
  • UV-C Bulbs for DEL AOP & UV-C 50: 18 months
  • Powerclean Salt Ultra: 3 year warranty (parts & labor)
  • Powerclean Salt Ultra Extended Life: 4 year warranty (parts & labor)
  • Powerclean Salt Econ: 2 year warranty (parts & labor)
  • Replacement for T-15 Cell: 2 year warranty

See warranty document for full warranty details.

This information was updated on 10/16/19. For the most current information and full warranty policy please visit www.c-m-p.com.
