Home Prozone PZ-784 Eco Master Germicidal UV with Advanced Oxidation Process AOP for Pools | 6 LPM | Up to 40,000 Gallons | Multi-Voltage | E23RE-08IA-P71
Prozone PZ-784 Eco Master Germicidal UV with Advanced Oxidation Process AOP for Pools | 6 LPM | Up to 40,000 Gallons | Multi-Voltage | E23RE-08IA-P71
This item has been discontinued.
Eco Master for Pools - Chemical free clean...it truly is the ideal swim experience
Prozone announces the next generation in pool water treatment. The Eco Master® combines state of the art, germicidal UV with Ozone and Advanced Oxidation Processing to deliver the most powerful non-chemical, non-chlorine, non-mineral oxidation and purification available for spas. The Eco Master®’s patented hybrid technology is light years ahead of traditional UV or Ozone.The Eco Master®, like all of Prozone’s designs, features an all in one design for easy installation. Dynamic flow venturi injectors are available in multiple sizes to accommodate flow rate. The system is covered by eighteen US patents, international patents, and patents pending.
The Eco Master® is the newest in our catalogue of eco-friendly, easy to maintain, and cost efficient products. Whether it is for the home pool or the commercial facility with heavy bather load, Prozone’s Eco Master® systems deliver clean, clear, healthy pool water that won’t irritate bathers or corrode surrounding surfaces.
Features
UV-C Germicidal Sterilization
Patented AOP Hybrid Technology
Ozone and Hydroxyl Purification
AOP Sanitation
Multi-voltage, Universal Ballast
Inline or By-Pass Installation
Static Mixer
Patented dynamic Venturi Injector
Specification
External Housing – 6061-T6 Aluminum Extrusion
Integrated Dynamic Venturi Injector
AOP Hybrid lamps
Pools up to 40,000 gal: Two 287 mm length Hybrid arc tube
Swim Spa or Small Pool to 15,000 gal: One 287 mm Hybrid arc tube
Ballast single 120 or 240 or Universal 90-260 V
Dimensions Spa: 8.5”X 6” X 3.5” or Custom Design
Nema Plug or 3 Wire Pigtail
Pure Quartz Glass AOP Chamber to Maximize UV-C
Low maintenance-Teflon coating
Long life – Full 2 year warranty, 20,000 hour lamp life
Start typing your question and we'll check if it was already asked and answered. Learn More
Do not include HTML, links, references to other stores, pricing or contact info.
My question is about:
If your question is about more than one item, click + to add them.
Browse 1 question
Browse 1 question
and 1 answer
What is the difference between Prozone EcoMaster model numbers PZ-684, -784 and -884 other that "LPM" performance chart? What is LPM, and is more better?
Prozone PZ-784 Eco Master Germicidal UV with Advanced Oxidation Process AOP for Pools | 6 LPM | Up to 40000 Gallons | Multi-Voltage | E23RE-08IA-P71
Prozone PZ-684 Eco Master Germicidal UV with Advanced Oxidation Process AOP for Pools | 3 LPM | Up to 40000 Gallons | Multi-Voltage | E23RE-08IA-P73
Prozone PZ-884 Eco Master Germicidal UV with Advanced Oxidation Process AOP for Pools | 9 LPM | Up to 40000 Gallons | Multi-Voltage | E23RE-08IA-P72
BEST ANSWER:My understanding is the number of UV lights in the unit. 1 in the 684, 2 in the 784, and 3 in the 884. Would be best to check directly with the manufacturer.
BEST ANSWER:My understanding is the number of UV lights in the unit. 1 in the 684, 2 in the 784, and 3 in the 884. Would be best to check directly with the manufacturer.
Prozone PZ-784 Eco Master Germicidal UV with Advanced Oxidation Process AOP for Pools | 6 LPM | Up to 40,000 Gallons | Multi-Voltage | E23RE-08IA-P71
This item has been discontinued.
Product description
Eco Master for Pools - Chemical free clean...it truly is the ideal swim experience
Prozone announces the next generation in pool water treatment. The Eco Master® combines state of the art, germicidal UV with Ozone and Advanced Oxidation Processing to deliver the most powerful non-chemical, non-chlorine, non-mineral oxidation and purification available for spas. The Eco Master®’s patented hybrid technology is light years ahead of traditional UV or Ozone.The Eco Master®, like all of Prozone’s designs, features an all in one design for easy installation. Dynamic flow venturi injectors are available in multiple sizes to accommodate flow rate. The system is covered by eighteen US patents, international patents, and patents pending.
The Eco Master® is the newest in our catalogue of eco-friendly, easy to maintain, and cost efficient products. Whether it is for the home pool or the commercial facility with heavy bather load, Prozone’s Eco Master® systems deliver clean, clear, healthy pool water that won’t irritate bathers or corrode surrounding surfaces.
Features
UV-C Germicidal Sterilization
Patented AOP Hybrid Technology
Ozone and Hydroxyl Purification
AOP Sanitation
Multi-voltage, Universal Ballast
Inline or By-Pass Installation
Static Mixer
Patented dynamic Venturi Injector
Specification
External Housing – 6061-T6 Aluminum Extrusion
Integrated Dynamic Venturi Injector
AOP Hybrid lamps
Pools up to 40,000 gal: Two 287 mm length Hybrid arc tube
Swim Spa or Small Pool to 15,000 gal: One 287 mm Hybrid arc tube
Ballast single 120 or 240 or Universal 90-260 V
Dimensions Spa: 8.5”X 6” X 3.5” or Custom Design
Nema Plug or 3 Wire Pigtail
Pure Quartz Glass AOP Chamber to Maximize UV-C
Low maintenance-Teflon coating
Long life – Full 2 year warranty, 20,000 hour lamp life
Internal reflective aluminum surface to maximize
Ozone and UV-C performance
Injector Performance Data
PZ 684
3 PSI
3 LPM
PZ 784 (std)
3 PSI
6 LPM
PZ 884
3 PSI
9 LPM
Features and details
Germicidal UV with Ozone and Advanced Oxidation Processing
Ozone and Hydroxyls make clean, healthy water without the addition of chemicals
Start typing your question and we'll check if it was already asked and answered. Learn More
Do not include HTML, links, references to other stores, pricing or contact info.
My question is about:
If your question is about more than one item, click + to add them.
Browse 1 question
Browse 1 question
and 1 answer
What is the difference between Prozone EcoMaster model numbers PZ-684, -784 and -884 other that "LPM" performance chart? What is LPM, and is more better?
Prozone PZ-784 Eco Master Germicidal UV with Advanced Oxidation Process AOP for Pools | 6 LPM | Up to 40000 Gallons | Multi-Voltage | E23RE-08IA-P71
Prozone PZ-684 Eco Master Germicidal UV with Advanced Oxidation Process AOP for Pools | 3 LPM | Up to 40000 Gallons | Multi-Voltage | E23RE-08IA-P73
Prozone PZ-884 Eco Master Germicidal UV with Advanced Oxidation Process AOP for Pools | 9 LPM | Up to 40000 Gallons | Multi-Voltage | E23RE-08IA-P72
BEST ANSWER:My understanding is the number of UV lights in the unit. 1 in the 684, 2 in the 784, and 3 in the 884. Would be best to check directly with the manufacturer.
BEST ANSWER:My understanding is the number of UV lights in the unit. 1 in the 684, 2 in the 784, and 3 in the 884. Would be best to check directly with the manufacturer.
