Home Pool Replacement Pump Motors Square Flange Motors Replacement Square Flange Pool & Spa Motor 56Y Frame Standard Efficiency | 115/230V 0.5HP Full Rated 0.75HP Up Rated | R0479310 | EB846 | EB852 | B2846 | B2852 | ASB846
NOTICE: The pool & spa industry continues to face industry-wide shortages on many products that most vendors expect to last late into 2022. ... We're allowing items to be purchased so that customers who choose to wait will have their order shipped when product is available. Most vendors are not providing any ETA on when items will be available. WE WILL EMAIL YOU RIGHT AWAY IF YOUR ITEM IS BACKORDERED.

Replacement Square Flange Pool & Spa Motor 56Y Frame Standard Efficiency | 115/230V 0.5HP Full Rated 0.75HP Up Rated | R0479310 | EB846 | EB852 | B2846 | B2852 | ASB846

$200.40
Replacement Square Flange Pool & Spa Motor 56Y Frame Standard Efficiency | 115/230V 0.5HP Full Rated 0.75HP Up Rated | R0479310 | EB846 | EB852 | B2846 | B2852 | ASB846
Innovative features, fast delivery, and exceptional reliability are the winning features built into every U.S. MOTORS® brand pool and spa motor Nidec Motor Corporation manufactures. Built-in, industry-leading features like angled terminal boards for convenient access...voltage selection with the flip of a switch...no-worry switches with no field adjustment needed...all help to make installing and maintaining these pool and spa motors much faster and easier than the competition.

Motor Features:
  • Two Compartment
  • 1081 Design
  • Open Drip-Proof
  • 300 Series Stainless Steel Shaft
  • Shaft Threads - 1/2-20 UNF-2A
  • Voltage Selection Device (Dual Voltage Only)
  • Switchless Design
  • 6.5" Diameter Frame
  • Double Sealed Ball Bearing
  • Continuous Duty
  • Class B Insulated
  • Thermally Protected
  • 50 Degree 'C' Ambient
  • Frequency: 60
  • Length Less Shaft: 11.99
  • Weight: 22
Specifications:
Type Standard Efficient
Rating Total Horsepower Rated
Speed Single
Frame Size/Diameter 56Y
Enclosure Open Drip Proof
Phase Category Single
Voltage 115/230
Frequency 60 Hz
Amps 5.4/10.8
Service Factor:
THP 0.95
RPM 3450
Shaft Type Threaded
Rotation CW Lead End
Mounting Square Flange

NOTE: Total Horsepower (Horsepower x Service Factor) of replacement motor must meet or exceed current pump motor.


Brand: US MOTORS
